Microsoft Azure: Implementing Internet Facing Load Balancer
Microsoft Azure: Implementing Internet Facing Load Balancers using Azure Resource Manager
In this Video, I will show you How to create an External Load balancer using Azure Resource Manager. We will create two load balanced web-servers publicly accessible through a common IP address.
Then we will test that load balancer through a common IP
Step 1: Create a VM in one region
Step 2: Create another VM in that region
Step 3: Create a Load Balancer
Step 4: Test Load Balancer
Create a new resource group
Create a new Virtual network
Create a Virtual Machine
Create a Availability Set
Select appropriate VM compute resources
Create another VM and add in same region and availability set
Create a Load Balancer for both VM
Create a new Probe
Add rule to redirect load balancer port
Test Load Balancer:
Test the LB by turnoff one VM
Thursday, 20 December 2018
Vnet-Vnet Between Different Region and Different Subscripiton
Overview:
This article helps you connect virtual networks (VNets) by using the VNet-to-VNet connection type. Virtual networks can be in different regions and from different subscriptions. When you connect VNets from different subscriptions, the subscriptions don't need to be associated with the same Active Directory tenant.
SetUp a xyz company network
Create a new Resource group :
Create a Virtual Network :
Create a Gateway Subnet :
Create a VM in your Virtual Network .
Create a Virtual Network Gateway
SetUp a ABC Company network
Create New resource group for abc company
Create a Virtual Network
Add SubNet
Create a new VM
Create a Virtual Network Gateway
Connect Abc and Xyz Virtual Network Gateway using Powershell CLI
Fetch the id for Vnet-Gateway using command :
az network vnet-gateway show -n xyz-vnet-gateway -g xyz-resgroup
Execute below command in Subscription 1:
az network vpn-connection create -n xyzvnet-abcvnet -g xyz-resgroup --vnet-gateway1 /subscriptions/subscription-id2/resourceGroups/xyz-resgroup/providers/Microsoft.Network/virtualNetworkGateways/xyz-vnet-gateway -l "West US 2" --shared-key "eeffgg" --vnet-gateway2 /subscriptions/subscription-id/resourceGroups/abc-resgroup/providers/Microsoft.Network/virtualNetworkGateways/abc-vnet-gateway
Execute below command in Subscription 2:
az network vpn-connection create -n abcvnet-xyzvnet -g abc-resgroup --vnet-gateway1 /subscriptions/subscription-id/resourceGroups/abc-resgroup/providers/Microsoft.Network/virtualNetworkGateways/abc-vnet-gateway -l "East US 2" --shared-key "eeffgg" --vnet-gateway2 /subscriptions/subscription-id2/resourceGroups/xyz-resgroup/providers/Microsoft.Network/virtualNetworkGateways/xyz-vnet-gateway
Test the connection :
Test the RDP using private IP from one machine to another machine.
